1/4″ 3000 Series Body 1/4″ NPT Male Thread
3050-2 – 1/4″ (-04) 3000 Series Ball Type High Pressure Hydraulic Quick Coupler Body – Carbon Steel – 1/4″ (-04) NPTF Male Thread
Web Price:
Original price was: R918.85.R735.08Current price is: R735.08.
Stock:
8 in stock
3000 Series Ball Type 1/4″ (-04) Coupler Body with 1/4″ (-04) NPTF Male Thread – Carbon Steel
High Pressure Ball Type Hydraulic Quick Coupler Body
Equivalent to Parker 3050-2
Also known as 10K, or 700Bar Series Quick Couplers
Threaded to Connect – Sleeve Type
Polyurethane Seal
Body Size: 1/4″
Thread Size: 1/4″-18 NPTF Male
Temperature Range: -30°C to +110°C
Pressure Rating: 10 000Psi – 700Bar
Rated Flow: 3gpm
The 3000 Series coupling are designed for high pressure applications. The coupler sleeve and nipple body must be manually threaded together to make the connection.
Features:
Manual threaded connection and actuation
Hard, chrome alloy ball valves
Polyurethane interface seal resists high pressure extrusion
Threaded retainer provides a positive valve stop
Protective zinc plating with clear trivalent chromate finish
Applications:
Hydraulic rams, Portable hydraulic tools, Crimping equipment
NPTF Stands for: National Pipe Taper Fuel (NPTF), also called Dryseal American National Standard Taper Pipe Thread, defined by ASME B1. 20.3, designed to provide a more leak-free seal without the use of PTFE tape (aka “Teflon”) or other sealant compound. NPTF can be used with normal NPT.
Other know codes: Q-10K-04F-BALL, 3050-2
PLEASE NOTE THAT COURIER COST MAY NOT BE 100% ACCURATE ON HOSE ASSEMBLIES OR BULK, IT IS ADVISED TO REQUEST COURIER COST SEPERATE UPON ORDERING. YOU ARE WELCOME TO CALL OR EMAIL TO GET ACCURATE COSTING ON COURIER PRIOR TO ORDERING.
Items in stock may sometimes differ slightly from those in the pictures, but they are functionally the same.
